Pusher Seals
Leading Manufacturers, Exporters, Wholesaler and Retailer of PS10B Pusher Seals, PS160-SPL Pusher Seals, Ps163 Pusher Seals, PS240 Pusher Seals, PS25 Pusher Seals, PS288 Pusher Seals, PS290 Pusher Seals, PS40P Pusher Seals, PS700N Pusher Seals, PSB500 Pusher Seals and PSRN Pusher Seals from Ghaziabad.
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Finishing | Polished |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
| Specialities | Single seal, Balanced, Independent of direction of rotation, Stationary multiple springs |
| Advantages | Insensitive to solids in the medium, Very short axial installation length (analog lip seals) combine |
| Operating range | Shaft diameter: d1 = 15 ... 100 mm (0.6" ... 3.9"), Pressure: p1 = 25 bar(363) PSI, Temperature: t = |
Preferred Buyer From
| Location | Anywhere in India |
Recommended Applications
- Process industry
- Chemical industry
- Water and waste water technology
- Lube oils
- Roller seal
- Bearing seal
- All seal chambers with a very short axial installation length
Materials
- Seal face: Carbon graphite antimony impregnated (A), Carbon graphite resin impregnated (B)
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Finishing | Polished |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
| Standards and approvals | ISO 3096 |
| Specialities | Single Seal, Balanced, Independent of direction of rotation, Stationary multiple springs |
| Advantages | Excellent torque transmission due to clutch drive between seal head and drive collar. |
| Operating range | Pressure: p = 12 bar (174 PSI), Temperature: t = -20 oC ... +160 oC (-4 oF ... 320 oF), Sliding velo |
Preferred Buyer From
| Location | Anywhere in India |
Recommended applications
- Process industry
- Oil and Gas Industry
- High viscous media (tar, heavy oils)
- Process pumps
Materials
- Seal face and seat: Silicon carbide (Q1), Tungsten carbide (U7)
- Secondary seals: FKM (V)
- Metal parts: CrNiMo steel (G)
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Finishing | Polished |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
| Specialities | Single seal, Unbalanced, Independent of direction of rotation, Positive torque transmission due to bayonet drive between seal head and drive collar, O-Ring groove for ventilation prevents solids build-up and enhances flexibility |
| Operating range | Pressure: p = 12 bar (174 PSI), Temperature: t = -20 oC ... 160 oC (-4 oF ... +320 oF), Sliding velo |
Preferred Buyer From
| Location | Anywhere in India |
Recommended Applications
- Pulp and paper industry
- Water and waste water technology
- High-viscosity liquids
- Pulp suspensions
- Process pumps
- Pulp pumps
Materials
- Seal face: Silicon carbide (Q1)
- Seat: Silicon carbide (Q1)
- Secondary seals: EPDM (E), FKM (V)
- Metal parts: CrNiMo steel (G)
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Material | Cold Rolled Steel |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
Preferred Buyer From
| Location | Anywhere in India |
Recommended Applications
- Water and waste water technology
- Drinking water
- Chemical industry
- Oil and Gas
- Petrochemical industry
- Refining technology
- Standards And Approvals
- EN 12756
- Pulp and paper industry
- Power plant technology
- Mining industry
- Metal production and processing
- Special applications (Cement, ...)
- Shipping Industry
Materials
- Seal face: Carbon graphite antimony impregnated (A), Carbon graphite resin impregnated (B), Silicon carbide (eSIC-Q7)
- Seat G6: Silicon carbide (eSIC-Q7)
- Secondary seals: E, EL, V, V16, K, KL, P
- Springs: CrNiMo steel (G)
- Face housing: CrNiMo steel (G)
- Driver: Duplex (G1)
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Specialities | External Configuration Balanced Independent Of Direction Of Rotation Independent Of Pressure Direction |
| Type | Industrial Seals |
| Country of Origin | India |
| Advantages | Robust and easy to install design, Springs protected from the product, No metal parts on the produc |
| Operating Range | Shaft diameter: d1 = 15 ... 300 mm (0.59 |
Preferred Buyer From
| Location | Anywhere in India |
Materials
- Seal face: Silicon Carbide (Q2), CrMo cast steel (S)
- Seat: Carbon graphite resin impregnated (B), Silicon carbide (Q2)
- Secondary seals: EPDM (E), NBR (P), FKM (V), FFKM (K), coated (M)
- Springs: CrNiMo steel (G)
- Metal parts: CrNiMo steel (G)
Recommended Applications
- Process industry
- Oil and gas industry
- Refining technology
- Petrochemical industry
- Chemical industry
- Pharmaceutical industry
- Power plant technology
- Water and waste water technology
- Mining industry
- Building services industry
- Food and beverage industry
- Shipbuilding
- Sugar industry
- Metal production and processing
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Finishing | Polished |
| Type | Industrial Seals |
| Country of Origin | India |
| Operating Limits | Shaft Dia. : 10 to 100mm Pressure : up to 10 Bars Temp. : -50 to 180OC Speed : up to 25 m/s |
| Applications | Generally used for handling corrosive chemicals, hydrocarbons, general & light chemicals |
Preferred Buyer From
| Location | Anywhere in India |
Type PS - 288 Multi Spring Reversed Balanced Seal is externally mounted internally balanced multi-coil spring seal. The unique feature of this type of seal is that, it eliminates the shaft step or sleeves for balancing.
These seals are externally mounted & hence the metal parts including the springs do not come in contact with the circulating media & therefore can be use for corrosive or abrasive media. sealing. The compact design eliminates the requirement of extra radial & axial space for its installation.
Material
- Seal Faces :- Sic/carbon Vs Ceramic/Sic./TC
- Secondary Seals :- Viton/PTFE/GFT
- Metal Components :- SS-316
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Finishing | Polished |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
| Specialities | For stepped shafts, Single seal, Balanced, Super-Sinus-spring or multiple springs rotating, Independent of direction of rotation, Integrated pumping device available (H7F, H75F), Variant with seat cooling available (H75G115) |
| Advantages | Universal application opportunities (standardization), Efficient stock keeping due to easily interch |
| Operating range | Seal face: Silicon carbide (Q1, Q2), Carbon graphite antimony impregnated (A), Aluminium oxide (V), |
Preferred Buyer From
| Location | Anywhere in India |
Materials
- Seal face: Silicon carbide (Q1, Q2), Carbon graphite antimony impregnated (A), Aluminium oxide (V), CrMo cast steel (S)
- Seat G9: Carbon graphite antimony impregnated (A), Carbon graphite resin impregnated (B), Silicon carbide (Q1*, Q2*)
- Secondary seals: EPDM (E), NBR (P), FKM (V), FFKM (K)
- Springs: CrNiMo steel (G)
- Metal parts: CrNiMo steel (G), Duplex (G1)
- * Cannot be combined with seal face made of S
Recommended Applications
- Process industry
- Oil and Gas Industry
- Refining technology
- Petrochemical industry
- Chemical industry
- Power plant technology
- Pulp and paper industry
- Food and beverage industry
- Hot water applications
- Light hydrocarbons
- Boiler feed pumps
- Process pumps
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Shape | Round |
| Specialities | Stationary Springs,Balanced,Independent Of Direction Of Rotation,Independent Of Pressure Direction |
| Type | Industrial Seals |
| Country of Origin | India |
| Advantages | Balanced seal in the installation space of a unbalanced seal, Springs protected from the product, Su |
| Operating Range | Shaft diameter: d1 = 18...300 mm, Pressure: p1 = 25 bar (363 PSI), Temperature: t = -40...220oC ( -4 |
Preferred Buyer From
| Location | Anywhere in India |
Recommended Applications
- Process industry
- Oil and gas industry
- Refining technology
- Petrochemical industry
- Chemical industry
- Pharmaceutical industry
- Power plant technology
- Pulp and paper industry
- Water and waste water technology
- Mining industry
- Building services industry
- Food and beverage industry
- Shipbuilding
- Sugar industry
- Metal production and processing
Materials
- Seal face: Silicon Carbide (Q1, Q2)
- Seat: Carbon graphite resin impregnated (B), Silicon carbide (Q1, Q2)
- Secondary seals: EPDM (E), FKM (V), FFKM (K)
- Springs: CrNiMo steel (G)
- Metal parts: CrNiMo steel (G)
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Material | Cold Rolled Steel |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
| Specialities | Single seal, Balanced, Independent of direction of rotation, Stationary multiple springs |
| Advantages | Unitized construction allows easy conversion, Springs located on the atmospheric side, no clogging, |
| Operating Range | Pressure: p = ... 35 bar ( ... 508 PSI), Temperature: t = 160 oC (320 oF), Sliding velocity: vg = 30 |
Preferred Buyer From
| Location | Anywhere in India |
Materials
- Seal face: High density carbon graphite (B)
- Seat: Silicon carbide (Q1)
- Secondary seals: FKM (V)
- Metal parts: 1.4401 (G)
Recommended Applications
- Chemical industry
- Refining technology
- Petrochemical industry
- Lubrication oil
- Light oil
- Gasoline
- Naphtha
- Water
- Process pumps
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Finishing | Polished |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
| Specialities | Single seal, Balanced, Independent of direction of rotation, Rotating multiple springs |
| Advantages | API 682 (Type A) compliant, Fits to EN and ANSI seal chambers, Optimized, narrow width seal face des |
| Operating Range | Pressure: p = vacuum ... 35 bar (508 PSI), Temperature: t = -20 oC ... +200 oC (-4 oF ... +392 oF), |
Preferred Buyer From
| Location | Anywhere in India |
Recommended Applications
- Chemical industry
- Process industry
- Acids
- Alkaline solutions
- Salt solutions
- Low viscosity oils
- Monomers
- Hydrocarbons
- Water
- Seawater
- Process pumps
Materials
- Seal face: Carbon graphite resin impregnated (B), High density carbon graphite
- Seat: Silicon carbide (Q1)
- Secondary seals: FKM (V)
- Metal parts: CrNiMo steel (G)
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Cold Rolled Steel |
| Finishing | Polished |
| Shape | Round |
| Type | Industrial Seals |
| Country of Origin | India |
| Advantages | Safe operation (no fractures) because of seal face locking by square pin, Spring unit averted from the product so no sticking and clogging of the springs, Suitable for pressure reversals, Operation in vacuum without additional seat locking possible, |
| Specialities | Single seal, Balanced, Independent of direction of rotation, Stationary springs, Dual seals in tande |
| Operating range | Shaft diameter: d = 18 ... 100 mm (0.71" ... 3.94"), Pressure: p1*) = 25 bar (363 PSI), Temperature: |
Preferred Buyer From
| Location | Anywhere in India |
Recommended Applications
- Water and waste water technology
- Refining technology
- Dirty, abrasive and solid containing media
- Fugitive hydrocarbons (no API seal!)
- Sticky and stringy media
- Chemical standard pumps
- Sewage pumps
Materials
- Seal face: Carbon graphite resin impregnated (B), Silicon carbide (Q1)
- Seat: Silicon carbide (Q1)
- Secondary seals: FKM (V), NBR (P), FFKM (K), PTFE (T)
- Springs: Hastelloy® C-4 (M)
- Metal parts: CrNiMo steel (G)
